　　applications: mobile phones, gps receivers, altimeter applications, personal navigation devices (pnd), digital cameras with altimeter function

　　description: the ms5561c is a smd-hybrid device including a precision piezo-resistive pressure sensor and an adc-interface ic. it uses a three-wire serial interface for communication. the module dimensions of 4.75 mm x 4.25 mm and a height of only 1.6 mm allows for up-to-date smd design. it provides a 16 bit data word from a pressure and temperature dependent voltage. the ms5561 is a low power, low voltage device with automatic power down (on/off) switching. a 3-wire interface is used for all communications with a micro-controller.

　　features:

　　•pressure resolution 0.1mbar
　　•operating temperature -40°c to 85°c
　　•supply voltage 2.2v to 3.6v
　　•low supply current, typ. 4µa
　　•standby current < 0.1µa
　　•calibrated temperature and pressure sensor for 2nd order compensation
　　•esd protected, hbm 4kv

　　典型应用: 手机，gps，高度计，个人导航设备（pnd），带高度功能的数码相机

　　产品描述: ms5561c由高精度的硅压阻压力传感元件和模数转换ic组成，通过3线接口和外部微控器通讯。传感器的尺寸为4.75 mm x 4.25 mm ，厚度仅为1.6 mm 。ms5561c提供16位的压力和温度数字输出，主要特点为低电压，低功耗，以及自动待机（on/off）功能。

　　特点:
　　•压力分辨率：0.1mbar
　　•工作温度：-40°c ~ 85°c
　　•供电电压：2.2v ~ 3.6v
　　•工作功耗：4µa
　　•待机功耗 < 0.1µa
　　•经过校正的温度和压力传感器，可供二次补偿
　　•esd保护，hbm 4kv

　　ms5561c气压传感器更多技术参数及规格书下载请浏览：http://www.sensorway.cn/sensors/456.html
　　
