　　applications: smartphones, tablet pcs, personal navigation devices

　　industries: consumer goods

　　description: the ms5637 is an ultra-compact micro altimeter. it is optimized for altimeter and barometer applications in smart-phones and tablet pcs. the altitude resolution at sea level is 13 cm of air. the sensor module includes a high-linearity pressure sensor and an ultra-low power 24 bit δσ adc with internal factory-calibrated coefficients. it provides a precise digital 24-bit pressure and temperature value and different operation modes that allow the user to optimize for conversion speed and current consumption. a high-resolution temperature output allows the implementation of an altimeter/thermometer function without any additional sensor. the ms5637 can be interfaced to any microcontroller with i²c-bus interface. the communication protocol is simple, without the need of programming internal registers in the device. small dimensions of 3 x 3 x 0.9 mm³ allow the integration in mobile devices. this new sensor module generation is based on leading mems technology and latest benefits from meas switzerland proven experience and know-how in high volume manufacturing of altimeter modules, which has been widely used for over a decade. the sensing principle employed leads to very low hysteresis and high stability of both pressure and temperature signal.

　　features:

　　•qfn package 3 x 3 x 0.9mm3
　　•high-resolution module, 13cm
　　•integrated digital pressure sensor (24-bit δσ adc)
　　•i2c interface
　　•operating temperature range -40 to 85°c
　　•extended pressure range 10 to 2000mbar

　　典型应用: 智能手机，平板电脑，导航仪

　　行业: 消费电子和家用电器

　　产品描述: ms5637是一款超小型的高度计，专为手机和平板电脑应用设计，海平面处高度分辨率为13cm。传感器包括高线性度的压力传感元件和超级低功耗的24位δσ adc，内置工厂校准系数。ms5637提供高精度的24位压力和温度数字输出，客户可以根据应用需要配置转换速度和功耗。高分辨率的温度输出可以同时实现温度计的功能。ms5637可以与所有形式的微控器配合，通讯协议非常简单，无需修改内部寄存器。3 x 3 x 0.9 mm³的小尺寸是手机应用的理想选择。这款新ag捕鱼王官方网站模块基于先进的mems技术，并受益于meas过去十几年来在研发和批量生产气压/高度计方面的经验，因此压力和温度信号的迟滞都非常小，而且稳定性非常好。

　　特点:

　　•qfn封装 3 x 3 x 0.9mm3
　　•高分辨率，13cm
　　•集成数字压力传感器（24-bit δσ adc）
　　•i2c接口
　　•工作温度：-40 ~ 85°c
　　•扩展量程可达10 ~ 2000mbar

　　ms5637-02ba03压力传感器更多技术参数及规格书下载请浏览：http://www.sensorway.cn/sensors/703.html
　　
