　　applications: diving computers and divers watches, mobile water depth measurement systems

　　description: the ms5541-30c is the high-pressure version of ms5541c pressure sensor module. it contains a precision piezoresistive pressure sensor and an improved version of the 16 bit micropower sensor interface ic known from the ms5535c. the esd sensitivity has been improved to 4kv on all pins. in addition to this the ms5541- 30c is from its outer dimensions compatible to the ms54xx series of pressure sensors. it uses an antimagnetic polished stainless steel ring for sealing with o-ring. the sensor provides 16 bit pressure and temperature data via a 3 wire serial interface that can be easily interfaced with 4 bit low power microcontrollers. 64 bit of factory programmed prom provides calibration data for a highly accurate pressure and temperature calculation.

　　features:

　　•resolution 3.0mbar
　　•supply voltage 2.2v to 3.6v
　　•operating current < 5µa
　　•standy current < 0.1µa
　　•-40°c to 85°c
　　•no external components required

　　典型应用: 潜水设备和潜水表，手持水深测量系统

　　产品描述: ms5541-30c是ms5541c的高压版本，由高精度的硅压阻压力传感元件和16位模数转换ic组成，防磁抛光不锈钢圈与o型圈配合用于防水。产品根据压力和温度变化产生的电压变化转换为16位数字输出，通过3线接口和外部微控器通讯，防静电能力达到4kv 。工厂编程的64位prom提供高精度的温度和压力校正。ms5541-30c在安装上与ms54xx系列压力传感器兼容。

　　特点:
　　•分辨率：3.0mbar
　　•供电电压：2.2v ~ 3.6v
　　•工作功耗 < 5µa
　　•待机功耗 < 0.1µa
　　•-40°c ~ 85°c
　　•无需外部元件

　　ms5541-30c压力传感器更多技术参数及规格书下载请浏览：http://www.sensorway.cn/sensors/453.html
　　
　　北京赛斯维测控技术有限公司产品咨询热线：010-84775646，84775648。
