　　applications: tire pressure sensor, consumer appliances, medical instrumentation, barometric pressure, altitude measurement

　　description: the 50 is a piezoresistive silicon pressure sensor packaged in a to-5 configuration. absolute pressure ranges from 0-15 to 0-500 psi are available. it is intended for high volume applications where small size, light weight, and low cost are required. this design is intended for non-corrosive gases and is not recommended for liquids. a gel filling can be applied to provide mild protection against humidity and dust. the devices are shipped in plastic anti-static shipping tubes for use with automated production equipment. for high volume gage applications, contact the factory.

　　features:

　　pc board mountable
　　 0-60 mv output
　　absolute pressure
　　 low cost
　　t0-5 package
　　-40ºc to 125ºc operating range
　　±0.25% pressure non-linearity
　　solid state reliability

　　典型应用: 轮胎压力，消费品，医疗器械，气压计，高度测量

　　产品描述: 50型硅压阻式压力传感器采用to-5封装，绝压量程从0~15到0~500psi。适合需要小型，质轻，低成本的大批量应用。测量介质为非腐蚀性气体。可以按照客户要求加胶防尘/防潮。产品采用塑料外壳包装运输。大批量表压应用请与meas联系。

　　特点:

　　pcb板安装
　　0~60mv输出
　　绝压
　　低成本
　　to-5封装结构
　　-40℃~ 125℃工作温度范围
　　±0.25%非线性
　　固态结构，性能可靠

　　50型压力传感器更多技术参数及规格书下载请浏览：http://www.sensorway.cn/sensors/177.html
　　
　　北京赛斯维测控技术有限公司产品咨询热线：010-84775646，84775648。
