　　applications: low humidity, meteorolog

　　industries: engine and vehicle

　　description: based on the rugged hs1101lf capacitive humidity sensor, hm1520lf is a dedicated humidity transducer designed for measurements at low humidity. direct measurement of dew point or water concentration can be easily obtained in really cost effective conditions. direct interface with a micro-controller is made possible with the module’s linear voltage output.

　　features:

　　tubular form for through wall mounting
　　product free from lead, cr(6 ), cd and hg
　　calibrated, linear voltage for easy electronic interface
　　typical 1 to 1.6 volt dc output for 0 to 20% rh at 5vdc supply
　　ratiometric to voltage supply
　　patented solid polymer structure
　　full interchangeability
　　not affected by water immersion
　　controlled temperature dependency

　　humidity sensor specific features:
　　not affected by long period at low humidity values
　　high resistance to chemical
　　fast response time

　　典型应用: 低湿度测量，气象站

　　行业: 发动机和机动车辆

　　产品描述: hm1520lf是一款基于耐用的hs1101lf传感元件的湿度探头，专为低湿度的精确测量而设计。 高性价比的露点和含水量直接测量。线性电压输出，可直接与微控器连接。

　　特点:
　　管状封装，方便安装
　　无铅，铬和汞
　　工厂校正，线性电压输出，方便电气连接
　　1v ~ 1.6v直流输出（0% ~ 20% rh @ 5vdc 供电）
　　与供电电压成比率
　　专利的固态聚合体结构
　　互换性好
　　不受浸水影响
　　温度依赖性小

　　湿度传感器特点：
　　不受长期低湿的影响
　　抗化学腐蚀
　　快速响应

　　hm1520lf湿度传感器更多技术参数及规格书下载请浏览：http://www.sensorway.cn/sensors/80.html
　　
