　　applications: non-rotating parts torque measurement, test and measurement, robitics and effectors, laboratory and research

　　industries: general industry

　　description: the cs1060 has been designed to measure reaction torque. its sensing element is based on thin layer strain gauges in a wheatstone bridge configuration providing excellent temperature stability. optionally the torque sensor can receive an on-board amplifier for high level output. intermediate ranges are available at no extra cost. with many years of experience as a designer and manufacturer of sensors, measurement specialties often works with customers to design or customize sensors for specific uses and testing environments. to meet your needs we also offer complete turnkey systems. the matched components (sensor, power, amplifier and digital display) are formatted, calibrated and ready for immediate use.

　　features:

　　ranges from ±5 nm to ±7000 nm (±4 lbf-ft to ±5600 lbf-ft)
　　suited for static applications
　　square male coupling
　　high level output model with integrated amplifier

　　典型应用: 非旋转部件扭矩测量，测试测量，机器人和执行器，实验室和研

　　行业: 工业控制

　　产品描述:

　　cs1060系列扭矩传感器主要用来测量静态扭矩。金属应变片组成的惠斯通电桥提供优异的温度稳定性，可选放大输出。作为拥有多年经验的ag捕鱼王官方网站设计和制造商，meas常常与客户合作，按要求定制适合特殊用途和测试环境的传感器。同时，我们也根据客户需要提供成套系统。配套元件（ag捕鱼王官方网站，电源，放大器和数显系统）配置统一，经过校正，可供客户立即使用。

　　特点:

　　量程：±5nm ~ ±7000nm（±4lbf-ft ~ ±5600lbf-ft）
　　静态应用
　　方形机械连接
　　可选放大输出
　　
　　cs1060系列扭矩传感器更多技术参数及规格书下载请浏览：http://www.sensorway.cn/sensors/554.html
　　
　　北京赛斯维测控技术有限公司产品咨询热线：010-84775646，84775648。
