applications: process controls, tank level measurement, filter performance monitoring, corrosive fluids and gas measurement systems, flow measurements
industries: general industry
description: the d5100 series from measurement specialties sets the price and performance standard for differential pressure transducers used in demanding environments. the amplified model of the d5100 series exceeds the latest heavy industrial ce requirements including surge protection and reverse polarity protection. the transducers have two pressure ports for high and low pressures and all wetted parts are made of 316l stainless steel. it comes in a variety of electrical configurations and ranges from 1 to 500 psi (up to 35 bar).
features:
heavy industrial ce approval (amplified only)
as low as ±0.1% pressure non linearity
rugged construction: can withstand 50g shock/20g vibration
up to -40°c to 125°c operating temperature range
excellent stability
various output, fitting, and electrical configuration options
典型应用: 过程控制，箱内液位测量，过滤器性能监控，腐蚀性液体和气体测量系统，流量测量
行业: 工业控制
产品描述: meas的d5100是适合苛刻环境使用的高性价比差压ag捕鱼王官方网站。传感器带浪涌保护和反极性保护，符合最新的工业ce要求。ag捕鱼王官方网站采用316l不锈钢封装，有高压和低压两个引压孔，均可与液体接触。d5100有多种电气配置可选，量程从1到500 psi（35 bar）。
特点:
通过重工业ce认证（仅限放大输出型）
±0.1% 非线性
坚固的结构：耐受50g冲击/20g振动
工作温度范围最大可达-40℃ ~ 125℃
稳定性优异
可选不同输出，连接头，和电气配置
