　　applications: transportation, vibration/shock monitoring, road vehicle testing, low frequency applications, modal analyses

　　description: the model 4630 is an ultra-stable triaxial accelerometer offering both static and dynamic response. the silicon mems accelerometer incorporates integral temperature compensation that provides a stable output over a wide operating range. the three independent circuit assemblies have independent signal conditioning and can operate on common or separate power supplies. the advanced mems sensing elements are gas damped in order to provide a wide stable frequency response.

　　features:

　　mems triaxial accelerometer
　　dc response, ultra-stable
　　-55°c to 125°c operating range
　　signal conditioned output
　　5,000g over-range protection
　　three independent circuits
　　low current consumption
　　ranges: ±2g to ±500g
　　low transverse sensitivity

　　典型应用: 运输，振动/冲击监测，道路机车测试，低频应用，模态分析

　　产品描述:

　　4630是一款超稳的，适合静态和动态测量。ag捕鱼王官方网站带有先进的温度补偿，在宽温度范围内提供非常稳定的输出。三个独立的处理电路密封在一起，可统一或单独供电。4630采用气态阻尼的mems感应元件，频率响应范围宽。

　　特点:

　　mems三轴加速度传感器
　　静态响应，超稳
　　工作温度：-55℃~125℃
　　信号处理输出
　　5000g过载保护
　　三个独立电路
　　低功耗
　　量程：±2 ~ ±500g
　　低横向灵敏度

　　4630加速度传感器更多技术参数及规格书下载请浏览：http://www.sensorway.cn/sensors/88.html
