7101a加速度传感器中英文产品介绍——赛斯维传感器网-ag捕鱼王官方网站

　　applications: vibration & shock monitoring, laboratory testing ,modal applications, high frequency applications, general purpose usage

　　description: the model 7101a is a miniature, high performance iepe accelerometer available in ±50g to ±1000g dynamic ranges. the accelerometer is designed for high frequency vibration and shock measurements and offers a wide bandwidth to >10khz utilizing stable piezo-ceramic crystals in annular shear mode. the model 7101a features a hermetically sealed titanium housing and the popular through hole mount configuration. the standard operating temperature range extends from -55°c to 125°c.

　　features:

　　miniature iepe accelerometer
　　lightweight, 2.4grams
　　±50g to ±1000g dynamic range
　　hermetically sealed, titanium
　　wide bandwidth to >10khz
　　-55° to 125°c operating range
　　through hole mount

　　典型应用: 振动和冲击监测，实验室测试，模态应用，高频应用，一般应用

　　产品描述:

　　7101a是一款小尺寸高性能iepe，采用环形剪切压电陶瓷晶体，动态量程从±50g到±1000g，适合高频振动和冲击测量，带宽可达10khz。7101a采用全密封钛金属外壳，通孔安装，工作温度范围从-55℃到125℃。

　　特点:

　　小型iepe加速度传感器
　　重量轻：2.4g
　　带宽可达10khz
　　±50g ~ ±1000g动态量程
　　环形剪切晶体
　　通过小孔安装
　　全密封，钛金属外壳
　　工作温度：-55℃ ~ 125℃

　　7101a加速度传感器更多技术参数及规格书下载请浏览：http://www.sensorway.cn/sensors/694.html

　　北京赛斯维测控技术有限公司产品咨询热线：010-84775646，84775648。
