- ms5535-30c压力传感器中英文产品介绍
- 来源：ag捕鱼王官方网站 发表于 2014/10/16
applications: mobile water depth measurement systems, diving computers and diving watches
description: the ms5535-30c is a high-pressure version of ms5535c pressure sensor module. it contains a precision piezoresistive pressure sensor and an adc-interface ic. it uses an antimagnetic polished stainless ring for sealing o-ring. it provides a 16 bit data word from a pressure and temperature dependent voltage. additionally the module contains 6 readable coefficients for a highly accurate software calibration of the sensor. ms5535- 30c is a low power, low voltage device with automatic power down (on/off) switching. a 3-wire interface is used for all communications with a microcontroller.
features:
•resolution 3.0 mbar
•supply voltage 2.2v to 3.6v
•low supply current < 5ua
•standy current < 0.1µa
•-40°c to 125°c operation temperature
•16 bit adc resolution pressure measurement and control systems
典型应用: 手持水深测量系统，潜水设备和潜水表
产品描述:
ms5535-30c是高压版本的ms5535c，由高精度的硅压阻传感元件和模数转换ic组成。防磁抛光金属环与o型圈配合用于密封。ag捕鱼王官方网站提供16位的压力和温度数字输出，同时还提供6个可读系数用于高精度的软件校正。ms5535-30c的主要特点是低电压、低功耗，以及自动待机（on/off）功能，通过3线接口和外部微控器通讯。
特点:
分辨率：3.0 mbar
供电电压：2.2v ~ 3.6v
低功耗：< 5ua
待机功耗：< 0.1µa
工作温度：-40°c ~ 125°c
16位adc分辨率
